100W 808nm CW Single Bar For Hair Removal Laser Stack

100W 808nm CW Single Bar For Hair Removal Laser Stack

Item No.: WC808SB100

Item Name: 100W 808nm CW Water Cooled Single Bar Diode Laser Optical Center Wavelength 808nm

Wavelength Tolerance 5nm

Output Power 100W Spectral Width FWHM 3nm

Spectral Width FW90%E 6nm

Send Inquiry
Product Details


100W 808nm CW Single Bar For Hair Removal Laser Stack


Item No.: WC808SB100
Item Name: 100W 808nm CW Water Cooled Single Bar Diode Laser

Specifications
Optical
Center Wavelength λ 808nm
Wavelength Tolerance ±5nm
Output Power 100W
Spectral Width FWHM ≤3nm
Spectral Width FW90%E ≤6nm
Fast Axis Divergence(FWHM) 40Deg
Slow Axis Divergence (FWHM) 10Deg
Polarization Mode TM
Slope Efficiency ≥1.0W/A


Electrical
Operating Current Iop ≤110A
Threshold Current Ith ≤20A
Operating Voltage Vop ≤2V
Power Conversion Efficiency ≥55%


Thermal
Operating Temperature 22~28℃
Storage Temperature 0-55℃
Wavelength Temperature Coefficient ~0.28nm/℃
Coolant Deionized Water
Flow Rate/Bar 0.4-0.7L/min
Max Inlet Pressure 380kPa
Resistivity 0.25-5MΩ*cm



Others:

Power from 100W to 10000W laser is available, please contact us for more details

Packing
Flight Case(According to your request)

Delivery
Normally 1-2 weeks after payment was well received,FedEx,DHL Express,UPS,TNT



Payment Term

T/T or Western Union are for your choices.
