17W 808nm 976nm 650nm Triple Wavelength Fiber Coupled Diode Laser With Red Aiming Beam

17W 808nm 976nm 650nm Triple Wavelength Fiber Coupled Diode Laser With Red Aiming Beam

17W 808nm 976nm 650nm Triple Wavelength

Fiber Coupled Diode Laser

With Red Aiming Beam

Send Inquiry
Product Details

17W 808nm 976nm 650nm Triple Wavelength fiber coupled diode laser with red aiming beam





Item No.: FC808976DL17
Item Name: 17W 808nm 976nm Fiber Coupled Diode Laser


808nm Beam
Center Wavelength λ 808nm ±5nm
Output Power 7W
Spectral Width FWHM 5nm
Operating Current Iop 8.5A
Threshold Current Ith 0.8A
Operating Voltage Vop 2.0V
Power Conversion Efficiency 45%


976nm Beam
Center Wavelength λ 976nm ±5nm
Output Power 10W
Spectral Width FWHM 5nm
Operating Current Iop 11.5A
Threshold Current Ith 0.5A
Operating Voltage Vop 1.9V
Power Conversion Efficiency 45%


Aiming Beam
Center Wavelength λ 650nm ±10nm
Output Power ~10mW
Operating Current Iop 100mA
Operating Voltage Vop 2.3V



Fiber
Fiber Bend Radius >60mm
Buffer Diameter 320um
Fiber Cladding Diameter 220um
Fiber Core Diameter 200um
Fiber Numerical Aperture 0.22NA
Fiber Connector SMA905
Fiber Length 1M


Thermal
Operating Temperature 15~55℃
Storage Temperature -30-70℃
Wavelength Temperature Coefficient ~0.3nm/℃
Lead Soldering Temperature, 10 Sec max 250℃



Order Procedure

1.Contact us for more details by email.

2.We send PI to you for payment, payment term is T/T or Western Union.

3.Once payment is done, we will arrange production.

4.Delivery time is 1-4 weeks depends on different order qty and request.

5.After delivery, we will send you DHL UPS FedEx TNT tracking no.

6.Quality warranty is 12 months.


Remarks

Other models are available upon your choices,such as with more functions, TEC,PD,Aiming Beam,Detachable Fiber,pls contact us freely.Drawing 2.jpg

Package Drawing



Factory View
