10W BNI Laser 976nm CW/QCW Fiber Coupled Diode Laser




Product Details




Specifications

Item No.: FC976DL10

Item Name: 10W 975nm/976nm/980nm CW/QCW/Pulse/ Multimode fiber coupled diode laser for laser pumping/material processing/industry/medical/printing/CTP/display/projection/defense/military and scientific research/optional red aiming beam/PD photodetector/thermistor/TEC peltier/fiber detector

Optical

Center Wavelength λ

976m

Wavelength Tolerance

±5nm

Output Power

10W

Spectral Width FWHM

≤5nm

>90% Energy

0.25NA

Slope Efficiency

0.8W/A

Fiber

Fiber Numerical Aperture

0.22NA

Fiber Core/Cladding Diameter

105um/125um/250um

Fiber Length

1m

Bending Radius

>30mm

Fiber Connector

Bare/CO/ST/SMA/FC

Electrical

Operating Current Iop

≤15A

Threshold Current Ith

≤2.9A

Operating Voltage Vop

≤2.3V

Power Conversion Efficiency

~48%

Thermal

Operating Temperature

15~55℃

Storage Temperature

-30-70℃

Wavelength Temperature Coefficient

~0.3nm/℃
