BNI 70W 975nm Fiber Coupled Diode Laser

BNI 70W 975nm Fiber Coupled Diode Laser

BNI 70W Fiber Coupled Diode Laser

For Pumping Laser Industry

Fiber coupled pulsed laser diode

Send InquiryChat Now
Product Details

BNI 70W 975nm Fiber Coupled Diode Laser

70W (2).JPG


BNI 70W Fiber Coupled Diode Laser for pumping,material,processing,industry,medical,printing,CTP,display,projection,defense,military and scientific research,optional red aiming beam,PD photodetector,thermistor,TEC peltier,fiber detector


Specifications

Item No.: FC975DL70

Item Name: BNI 70W Fiber Coupled Diode Laser

Optical

Center Wavelength λ

975nm

Wavelength Tolerance

±10nm

Output Power

70W

Spectral Width FWHM

3.5nm

>90% Power

0.15NA

Slope Efficiency

5.8W/A

Fiber

Fiber Bend Radius

>60mm

Fiber Core/Cladding/Buffer Diameter

105um/125um/250um

Fiber Numerical Aperture

0.22NA

Fiber Length

1m

Fiber Connector

SMA/CO/Bare

Electrical

Operating Current Iop

13A

Threshold Current Ith

0.6A

Operating Voltage Vop

12V

Power Conversion Efficiency

47%

Thermal

Operating Temperature (Non-Condensing)

15~35℃

Storage Temperature (Non-Condensing)

-30-70℃

WavelengthTemperature Coefficient

~0.3nm/℃



Product Details






Packing
Flight Case(According to your request).

Delivery
Normally 1-2 weeks after payment was well received,FedEx,DHL Express,UPS,TNT.



Payment Term
T/T or Western Union are for your choices.

Return Policy
If Return, Buyer Pay the Shipping Cost.
