3000W 8xxnm 9xxnm Water Cooled Vertical Stack Diode laser with high quality and competitive price

Send InquiryChat Now
Product Details

Powerful 3000W 8xxnm 9xx Diode Laser Horizontal Bar Array for Industry,Militaray


Specifications

Optical

Center   Wavelength λ
808nm 940nm 976nm 915nm
Wavelength   Tolerance
±15nm
Working Mode
QCW
Output Power   Per Bar
100W
30Number of   Bars
30
Bar to Bar   Spacing
2mm
Fast Axis   Divergence(FWHM)
38Deg
Slow Axis   Divergence (FWHM)
12Deg
Polarization   Mode
TE
Slope   Efficiency
≥1.0W/A
Pulse Width
≤400ms
Duty Cycle
≤40%
Electrical

Operating   Current Iop
55A
Threshold   Current Ith
12A
Operating   Voltage Vop
21V
Power   Conversion Efficiency
45%
Power   Conversion Efficiency
45%
Thermal

Operating Temperature (No   Condensation)
15~30℃ (No Condensation)
Storage   Temperature (No Condensation)
0-55℃(No Condensation)
Storage   Temperature (No Condensation)
0-55℃(No Condensation)

QQ截图20180130173351QQ截图20180130173443QQ截图20180130173511QQ截图20180130154147QQ截图20180130154220QQ截图20180130154243
CT-Express


Brandnew Technology, one of the leading diode laser manufacturers and suppliers in China, has a professional factory which manufacturers high quality powerful diode laser stack 3000w 808nm 915nm 940nm 976nm and sells at competitive price. Welcome to wholesale our products made in China.
