60W 885nm Fiber Coupled Laser Diode
Application:
Scientific
Printing
IR Illuminate
Our 60W 885nm fiber-coupled diode laser stands out with its impressive array of features. It incorporates a precision 0.22NA 105μm core multimode fiber, ensuring efficient and accurate light delivery. Wavelength stability is a hallmark, with fluctuations limited to just ±1nm, providing the reliability needed for precision applications. Housed within a robust parallel weld 2-Pin sealed package, this laser diode is built to withstand demanding operational conditions. Furthermore, its narrow linewidth adds to its versatility, making it an ideal choice for applications requiring precise spectral characteristics. Experience the power, precision, and durability of this exceptional diode laser, tailored to excel in a wide range of applications.
Date sheet
Item NO.: FC885WS60
| Optical | |
| Center Wavelength | 885nm |
| Wavelength Tolerance | ±1nm |
| Output Power | 60W |
| Fiber | |
| Fiber Core | 105um |
| Fiber Numerical Aperture | 0.22NA |
| Fiber Length | 1m |
| Fiber Connector | SMA905 |
| Electrical | |
| Operating Current Lop | 11A |
| Threshold Current Lth | 1A |
| Operating Voltage Vop | 15V |
| Thermal | |
| Test Temperture | 25℃ |
| Wavelength Temperature Coefficient | 0.02nm/℃ |
Dimensions:
