Single Bar 50W 940nm Micro Channel Diode Laser For Pumping

Single Bar 50W 940nm Micro Channel Diode Laser For Pumping

Item No:MC940DL50
Send Inquiry
Description

Hangzhou Brandnew Technology Co., Ltd. is one of China's leading manufacturers and premier suppliers of advanced Single Bar 50W 940nm Micro Channel Diode Laser For Pumping. Operating a state-of-the-art factory, we specialize in the entire production spectrum—from high-performance chips, TO/F/C Mounts, COS, and MCC bars, to robust stacks and advanced fiber-coupled solutions.



Single Bar 50W 940nm Micro Channel Diode Laser For Pumping

This 50W 940nm single-bar micro-channel diode laser combines 940nm infrared emission with an integrated micro-channel cooling structure. Delivering an optical output power of 50W, the device is engineered for applications where efficient heat dissipation is a critical factor in laser system design

1 logo
Feature:
  • It delivers stable 940 nm near infrared laser output, suitable for material processing and optical applications, while ensuring consistent wavelength performance.

  • Based on a compact and highly integrated single bar architecture, it achieves CW optical output power up to 50 W.

  • Adopting a micro channel cooler design, it can significantly increase the heat‑transfer surface area and reduce thermal resistance.

  • Superior thermal management design ensures reliable performance even under long term operating stress.

  • Compatible with external beam shaping optics for easy collimation to meet specific application requirements.

Item No:MC940DL50

Optical
Center Wavelength 940nm
Wavelength Tolerance

±10nm

Working Mode CW
Output Power 50W
Number of Bars 1
Fast Axis Divergence(FWHM) 40Deg
Slow Axis Divergence (FWHM) 10Deg
Electrical
Threshold Current lth 8A
Operating Current lop 50A
Operating Voltage Vop 1.8V
Thermal
Test Temperature 25°C
Storage Temperature 0-55 ℃
Coolant Distilled Water
Flow Rate/Bar 0.3L/min
Max Inlet Pressure 350~500kPa
Water Temperature(No Condensation) 23~27 ℃
Filtered Water Particles <20um

Drawing

product-1-1

FAQ





product-470-408

01.What does "Single Bar" mean?

It means the laser source contains one individual laser diode bar, rather than a multi-bar stacked assembly.

02.Is this laser designed for CW operation?

Yes. This model is designed for continuous-wave operation at the specified operating conditions.

03.Can the output beam be shaped?

Optical accessories such as fast-axis collimators (FAC) can be used depending on the required beam distribution.

04.Can the product be customized?

Customization is available based on parameters such as bar configuration, quantity, output power, cooling structure, and optical design.
