808nm 50W Multimode Fiber Laser Diode Module

808nm 50W Multimode Fiber Laser Diode Module

0.22NA 400um core multimode fiber
Send Inquiry
Description

Hangzhou Brandnew Technology Co., Ltd. is one of China's leading manufacturers and premier suppliers of advanced 808nm 50w multimode fiber laser diode module. Operating a state-of-the-art factory, we specialize in the entire production spectrum—from high-performance chips, TO/F/C Mounts, COS, and MCC bars, to robust stacks and advanced fiber-coupled solutions.



808nm 50W Multimode Fiber Laser Diode Module with 0.22NA 400um Fiber

We deliver 808nm 50W Multimode Fiber Laser Diode Module employing professional coupling technology, that enjoy multiple advantages.This laser diode modules can provide a unique solution for the market,offering powerful technical attributes in a cost-effective package.


Advantages:

◆ compact design ◆ stable output power ◆ high power
◆ high efficiency ◆ long lifetime ◆ convenient packaging



Applications:
● Medical ● Lighting
● Pump Source ● Material Processing


Specifications:


Output Power50W
Center Wavelength808nm
Spectral Width3.5nm
Threshold Current1.0A
Operating Current9.0A
Operating Voltage12.0V
Convention Efficiency40%
95% Power0.18NA
Wavelength Shift vs. Temperature0.3nm/℃
Slop Efficiency6.0W/A
Storage Temperature-30~70°C(Non-Condensing)
Operating Temperature15~35°C
Fiber Bend Radius150mm
Core Diameter400μm
Numeric Aperture0.22
Fiber ConnectorBARE

Dimension:

Dimension
