40mW 1530nm Fiber Coupled Diode Laser
Features:
- Single Mode, Fiber type PM
- 1530nm center wavelength, 40mW output power
- Butterfly fiber coupled diode laser
- PD, TEC, Thermistor available
- FC/APC Connector
Applications:
- Raman spectrometer
- Medical use
- Upconversion material
- Partical size analyze
- This fiber-coupled diode laser delivers an output power of 40mW and boasts high efficiency.
- Additionally, the laser, operating at 1530nm, incorporates TEC (Thermoelectric Cooler), a photodiode, and a thermistor.
- Brandnew employs exclusive processes in diode manufacturing and fiber alignment/preparation to produce a module with low-noise output.
- This ensures superior beam quality, making it suitable for applications like spectroscopy and free-space optical communications.
Data sheet
Item No.: FC1530PM004
| Optical | |
| Center Wavelength | 1530nm |
| Wavelength Tolerance | ±1nm |
| Output Power | 40MW |
| Fiber | |
| Fiber Core | 9um |
| Fiber Connector | FC/APC |
| Fiber Length | >1m |
| Electrical | |
| Operating Current Lop | 300mA |
| Threshold Current Lth | 55mA |
| Operating Voltage Vop | 2.5V |
| PD | Available |
| TEC | Available |
| Thermistor | Available |
| Thermal | |
| Test Temperature | 25℃ |
Laser Drawing:
Product Overview:
1530nm, 40mW Laser Diode, PM Fiber-Coupled
1530nm, 40mW Laser Diode, PM Fiber Coupled
This BrandNew laser comes in a polarization maintained fiber coupled coaxial package. The laser is coupled to a 9 μm fiber, NA 0.12, terminated with an FC/APC connector. Other options are available; please inquire for options and details.
High Product Quality
Proprietary design, packaging, and fiber coupling processes produce laser diodes with extremely high stability and low noise. Each laser diode undergoes extensive testing and burn-in prior to shipment to ensure the highest possible level of quality and long-term reliability.
