65W 878nm Stabilized Fiber Coupled Laser Diode
Features:
- 878.6nm wavelength, ±1nm wavelength tolearance
- Uniform intensity distribution
- High saturation output power
Applications:
- Fiber Laser Pumping
- Material Processing
- Bio-medical instrument
Specification
Item NO.: FC8786WS65
Item Name: 878.6nm 65W Fiber Coupled Diode Laser
| Optical | |
| Center Wavelength | 878.6nm |
| Wavelength Tolerance | ±1nm |
| Output Power | 65W |
| Fiber | |
| Fiber Core | 200um |
| Fiber Connector | SMA905 |
| Fiber N.A. | 0.22NA |
| Fiber Length | 1m |
| Electrical | |
| Operating Current Lop | 14A |
| Threshold Current Lth | 2A |
| Operating Voltage Vop | 10V |
| Thermal | |
| Test Temperature | 25℃ |
| Operating Temperature | -30~70℃ |
| Wavelength Temperature Coefficient | 0.02nm/℃ |
Laser Size:
878nm 65W Fiber Coupled Diode Laser Structure of VBG Laser Diode:
Working of VBG Laser Diode
Looking for a reliable high-power laser source with exceptional wavelength stability? Our 878nm 65W fiber-coupled diode laser integrates Volume Bragg Grating (VBG) technology for narrow linewidth, minimal wavelength drift, and outstanding spectral stability - even under demanding operating conditions.
Advantages of 878nm 65W Fiber Coupled Diode Laser VBG Laser Diode：
- Improved spectral stability
- Cost-effective and easy to implement
- Less cooling requirements
- Improved emission characteristics
- Increased pumping efficiency
- Ability to operate at high powers
- Not necessary that the source be coupled into the fiber
- Consistent pumping efficiency over wide temperature ranges and drive currents
-
With VBG.
-
This fiber-coupled laser diode utilizes a 200μm, 0.22NA configuration, delivering an impressive output power of 65W.
-
Its versatility allows for application in various fields, including pumping fiber lasers, medical treatments, semiconductor lasers, fiber lasers, and material processing.
-
The incorporation of advanced technology, enhances its performance and applicability across multiple domains.
Possible application scenarios of 878.6nm in PDT:
1. Deep Tissue Penetration：
Advantage: 878.6nm belongs to the near infrared region (NIR), which has stronger tissue penetration ability than traditional PDT wavelengths (e.g. 630nm, 690nm).
Suitable for: targeted irradiation of deep tumours or visceral tissues, such as prostate cancer, pancreatic cancer, etc.
Limitation: need to be used with photosensitiser sensitive to this wavelength (absorption peak of traditional photosensitiser such as Photofrin, Chlorin e6 is not at 878nm).
