1W 808nm 9mm TO Laser Diode
Features:
1watt output power, 808nm wavelength
optimum performance, low maintenance, dimensionally accurate and easy to install
Application:
laser pumping,material processing,industry,medical,printing,display,projection,defense,military and scientific research.
Note:
Absolute Maximum Ratings may be applied to the Device for short period of time only. Exposure to maximum ratings for extended period of time or exposure above one or more max ratings may cause damage or affect the reliability of the Device.
Data sheet:
Item No.: TO808DL1
Item Name: 1W 808nm 9mm TO LD
| Optical | |
| Center Wavelength | 808nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 1W |
| Fast Axis Divergence | 38Deg |
| Slow Axis Divergence | 12Deg |
| Electrical | |
| Operating Current Iop | 1.2A |
| Threshold Current Ith | 0.2A |
| Working Voltage | 2.2V |
| LD Reverse Voltage | <2V |
| Slope efficiency | 1.1W/A |
| Thermal | |
| Operating Temperature | 25℃ |
| Storage Temperature | -40~80℃ |
Drawing:
FAQ:
Could you do OEM(design and manufacture lasers for customer)?
Yes, we we have professional R&D team including software, hardware, electronics and designers 3D department and have enough ability to manufacture lasers completely according to customer's requirements.
What is your terms of payment?
T/T or Western Union, for your choice.
