Hangzhou Brandnew Technology Co., Ltd. is one of China's leading manufacturers and premier suppliers of advanced 1w 830nm to laser diode for ctp. Operating a state-of-the-art factory, we specialize in the entire production spectrum—from high-performance chips, TO/F/C Mounts, COS, and MCC bars, to robust stacks and advanced fiber-coupled solutions.
1W 830nm TO Laser Diode for CTP
Special design for Screen CTP Plate Belichter
Data sheet:
Item No.: LD830TO1
Item Name: 1W 830nm 9mm TO LD
| Optical | |
| Center Wavelength | 830nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 1W |
| Fast Axis Divergence | 35Deg |
| Slow Axis Divergence | 10Deg |
| Electrical | |
| Operating Current Iop | 1A |
| Threshold Current Ith | 80mA |
| Working Voltage | 2V |
| LD Reverse Voltage | <2V |
| Slope efficiency | 1.1W/A |
| Thermal | |
| Operating Temperature | -40~70℃ |
| Storage Temperature | -40~80℃ |
Drawing:
FAQ:
Do you have any MOQ limit?
Low MOQ, 10pcs for sample checking is available
Do you offer guarantee for the products?
Yes, all products have been tested before shipping out.
Lifelong technique support. 2 years warranty.
