Description
40W 808nm Fiber Coupled Diode Laser
Key features:
Stabilized wavelength: 808±0.6nm at 25°C
Fiber: 200um/0.22NA/SMA905/2m
Fiber is metal-coated, Air-cooled Fiber, electrically isolated.
Data sheet
Item No.: FC808DL40
| Optical | |
| Center Wavelength | 808±0.6nm |
| Output Power | 40W |
| Working Mode | CW |
| Spectral Width FWHM | 1nm |
| Fiber | |
| Fiber Length | 2m |
| Fiber Core | 200um |
| Fiber Numerical Aperture | 0.22NA |
| Detachable Fiber Connector | SMA905 |
| Electrical | |
| Operating Current Iop | 8A |
| Threshold Current Ith | 1.5A |
| Operating Voltage Vop | 13V |
| Power Conversion Efficiency | 35% |
| Thermal | |
| Operating Temperature(Non-Condensing) | 20~30℃ |
| Storage Temperature(Non-Condensing) | -30~70℃ |
| Wavelength Temperature Coefficient | 0.02nm/℃ |
Drawing size
