Description
Hangzhou Brandnew Technology Co., Ltd. is one of China's leading manufacturers and premier suppliers of advanced 808nm fiber diode laser module. Operating a state-of-the-art factory, we specialize in the entire production spectrum—from high-performance chips, TO/F/C Mounts, COS, and MCC bars, to robust stacks and advanced fiber-coupled solutions.
90W 808nm CW Fiber Coupled Diode Laser Module with 400um, 0.22NA fiber,with power 10w,30w,50w 90w
Application:
Pumping
Medical
Material Processing
Illumination
Scientific Research
Specifications:
| Optical Characteristics | |
| Center Wavelength λ | 808nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 90W |
| Fiber Parameters | |
| Fiber Numerical Aperture | 0.22NA |
| Fiber Core/Cladding Diameter | 400μm/440um |
| Connector Type | SMA905 |
| Fiber Length | 1m |
| Electrical Characteristics | |
| Operating Current Iop | ≤12A |
| Threshold Current Ith | ≤1.7A |
| Operating Voltage Vop | ≤18V |
| Thermal Parameters | |
| Operating Temperature | 10~35°C |
| Storage Temperature | -40~80°C |
PIV data:
