1000W 915nm Fiber Coupled Diode Laser

Brandnew introduced the idea of dense spatial beam combination(DSBC) and proved it experimentally with kW level pump source. Currently, the output power of single emitters has reached 15W~30W@BPP≈5-12mm·mrad with electro-optical efficiency<60%. This makes it possible for the high-power pump source with optical fiber output to maintain high brightness, small volume, and light weight. With commercial available chips, Brandnew achieved 1000W output at 915nm (or 976nm) from a 200μm core diameter 0.22NA fiber is obtained and mass of ≈400g. In the future, with increasing diode chip brightness and electro-optical efficiency, the pump source with high power and mass ratio will have an important role in small size and high power fiber lasers, which will become an active driver for defence and industrial applications.
