Description
10W 1064nm CW Detachable Fiber Diode Laser
Features:
- 10W stable CW output, 1064nm IR wavelength
- 200um fiber core + SMA905 connector, detachable design
- High coupling efficiency, compact size, easy integration
Applications:
- Industrial Laser Pumping: Mid-power pump source for fiber/solid-state lasers (marking, micro-welding)
- Precision Material Processing: Laser annealing, surface modification of small industrial components
- OEM Laser Modules: Custom integration for industrial IR laser systems and test equipment
A high-performance 10W 1064nm CW fiber diode laser, featuring 200um fiber core, SMA905 connector and practical detachable fiber design. It delivers stable infrared output with low loss, easy maintenance and seamless integration, ideal for industrial pumping, precision processing, sensing and custom laser module manufacturing-combining reliability, flexibility and cost-effectiveness in one compact solution.
Data Sheet
Item No: FC1064CB10
| Optical | |
| Center Wavelength 1 | 640nm/0.5W |
| Center Wavelength 2 | 1064nm/10W |
| Working Mode | CW |
| Fiber | Detachable |
| Fiber Core | 200um |
| Fiber Numerical Aperture | 0.22NA |
| Fiber Length | 1m |
| Fiber Connector | SMA905 |
| Electrical | |
| Operating Current Iop | 1~13A |
| Threshold Current Ith | 0.5~2A |
| Operating Voltage Vop | 1.6~4V |
| PD | Optional |
| Thermistor | Optional |
| Thermal | |
| Test Temperature | 25℃ |
| Storage Temperature | -30~70℃ |
Drawing:
