50W 880nm Fiber Coupled Diode Laser
50W 880nm Fiber Coupled Diode Laser
Features
- Compact design with reliable thermal management
- Long lifetime and stable performance
- High stability and efficiency
- Detachable
Applications:
- Scientific research experiments
- Illumination and spectroscopy
Specification
Item No.: FC880DL50
Item Name: 880nm 50W Fiber Coupled Diode Laser
| Optical | |
| Center Wavelength | 880nm |
| Wavelength Tolerance | ±10nm |
| Spectrum Width FWHM | 6nm |
| Output Power | 50W |
| Fiber | |
| Fiber Core | 200um/400um |
| Fiber NA | 0.22NA |
| Fiber Length | 1m/0.9mm Jacket |
| Fiber Connector | SMA905 |
| Electrical | |
| Operating Current Iop | ＜12A |
| Threshold Current Ith | 2A |
| Operating Voltage Vop | ＜12V |
| Thermal | |
| Working Temperature | -10~55℃ |
| Storage Temperature | -26~65℃ |
| Wavelength Temperature Coefficient | 0.35nm/℃ |
Drawing
Our 880nm Fiber Coupled Diode Laser is built to deliver steady power with reliable performance. Designed with efficient fiber coupling, it runs stably even in demanding use. Many of our customers use it as a pumping source, in medical equipment, or for research, and it has proven to be a solid, long-lasting solution. Easy to integrate and backed by consistent quality, it's a laser you can count on.
Our 50W 880nm fiber-coupled diode laser is designed for users who require consistent, stable performance. This laser delivers pure optical power via fiber, offering easy installation and stable operation. Many partners use it in research laboratories, medical equipment, and as a pump source, demonstrating exceptional durability over long periods of use.
