1.8W 638nm Laser Diode Fiber Optic Coupling For Medical Application
Features：
- Center Wavelength：638nm
- Output Power：1.8W
- Fiber Core Diameter:200um
Applications：
- Fiber optical communications system
- Fiber optical networks
- Medical diagnosis
- Material Processing
- Spectrum analysis
1.8W 638nm Fiber Coupled Diode Laser has a wavelength of 638nm, just 1.8W output power, a fiber core diameter of 200um, and an output power of 1.8W, It has the characteristics of high efficiency, high stability and high cost performance. The package adopts 9-Pin package, which can be customized by customers, and the photodetector is optional.
Data Sheet
Item No: FC638DL1.8
Item Name: 1.8W Laser Diode Fiber Optic Coupling
|
Optical |
|
|
Center Wavelength |
638nm |
| Wavelength Tolerance | ±10nm |
|
Output Power |
1.8W |
|
Fiber |
|
| Fiber Core Diameter |
200um |
|
Fiber Numerical Aperture |
0.22NA |
|
Fiber Length |
1m |
|
Fiber Connector |
FC/PC |
|
Electrical |
|
|
Operating Current Iop |
2.8A |
|
Threshold Current Ith |
0.8A |
|
Operating Voltage Vop |
2.8V |
|
Thermal |
|
|
Operating Temperature |
15~35℃ |
|
Storage Temperature |
-20-70℃ |
Drawing:
Typically, the connectors for optical coupling are the ones shown below：
The connectors are different for different occasions, so they need to be based on the place
The most commonly used nowadays is FC/PC
Packing & Warranty
