808nm 20W CW/QCW Medical Fiber Coupled Diode Laser
Advantages
High stability
0.22NA 200μm core multimode fiber
RoHS compliance
Applications
Pumping
Material Processing
Medical
Introducing our 808nm 20W CW/QCW Medical Fiber Coupled Diode Laser. With high stability and RoHS compliance, it ensures reliable performance. Equipped with a 0.22NA 200μm core multimode fiber, it offers versatility and precision. Ideal for pumping, material processing, and medical applications, this laser delivers exceptional results. Experience efficiency and accuracy with our state-of-the-art diode laser solution.
Item no.:FC808DL20
|
Optical |
|
|
Center Wavelength λ |
808nm |
|
Wavelength Tolerance |
±5nm |
| Working Mode | CW |
|
Output Power |
20W |
|
Spectral Width FWHM |
7nm |
|
>90% Power |
0.15NA |
|
Slope Efficiency |
2.45W/A |
|
Fiber |
|
|
Fiber Bend Radius |
＞60mm |
|
Fiber Core/Cladding/Buffer Diameter |
200um/240um/320um |
|
Fiber Numerical Aperture |
0.22NA |
|
Fiber Length |
1m |
|
Fiber Connector |
SMA905 |
|
Electrical |
|
|
Operating Current Iop |
9.8A |
|
Threshold Current Ith |
1.7A |
|
Operating Voltage Vop |
5.4V |
|
Power Conversion Efficiency |
39% |
|
Thermal |
|
|
Operating Temperature (Non-Condensing) |
15~55℃ |
|
Storage Temperature (Non-Condensing) |
-30-70℃ |
|
Wavelength Temperature Coefficient
|
～0.3nm/℃ |
