Hangzhou Brandnew Technology Co., Ltd. is one of China's leading manufacturers and premier suppliers of advanced 30w laser pumping source fiber coupled laser. Operating a state-of-the-art factory, we specialize in the entire production spectrum—from high-performance chips, TO/F/C Mounts, COS, and MCC bars, to robust stacks and advanced fiber-coupled solutions.
Pumping Source 30W 915nm Fiber Coupled Diode Laser
Features：
- Compact design
- Stable and high output power
- High efficiency
- long lifetime
- With Jenoptik Laser Chips
Application:
- Fiber Laser Pumping Source
- Laser Lighting
- Scientific Research
- Display Entertainment
30W 915nm Fiber Coupled Diode Laser offers high brightness, a small footprint, and simplified thermal management by distributing the diodes (heat sources), allowing the use of air-cooled or water-cooled structures with predictable high reliability.
Data Sheet
Item No: FC915DL30
Item Name: 30W Laser Pumping Source Fiber Coupled Laser
| Optical | |
| Center Wavelength λ | 915nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 30W |
| Fiber | |
| Fiber Core | 200um |
| Fiber Numerical Aperture | 0.15NA |
| Fiber Length | 1m |
| Fiber Connector | SMA905 |
| Electrical | |
| Operating Current Iop | 13A |
| Threshold Current Ith | 1A |
| Operating Voltage Vop | 4V |
| Thermal | |
| Test Temperature | 25℃ |
| Storage Temperature | -30-70℃ |
| Wavelength Temperature Coefficient | ~0.3nm/℃ |
Drawing:
915nm 30W fiber-coupled semiconductor laser products are produced by BNT fully automated production equipment to ensure consistent performance, and have been put on the market in batches for many years. In addition to this product, BNT also provides 405nm-1940nm, 2mW-4kW products. Provide customers with customized products and services. Today, BNT is gradually developing into a global leader in the field of laser solutions, with products in more than 70 countries and regions around the world. There are more than 10 million lasers running online in the world, and the applications involve many fields such as industry, medical treatment, business, scientific research, information, etc., bringing new changes to the development of the industry and the enhancement of customer value.
