Description
1W 520nm Green TO9 Laser Diode
Product Description
Applications:
- Architecture / Garden Lighting (LED & Laser)
- Area Lights
- Downlights/Spotlights
- Industry
- Measurement Levelling
- Mood Lighting
- Street, Tunnel and Outdoor
Features:
- Optical output power (continuous wave): 1W (TC = 25°C)
- Typical emission wavelength: 520 nm
- Efficient radiation source for cw and pulsed operation
- Single mode semiconductor laser
- High modulation bandwidth
- TO56 package with photo diode
- Cathode is electrically connected to the case
Data sheet:
Item No.: TO520DL1
Item Name: 1W 520nm TO-Mount Laser Diode
| Optical | |
| Center Wavelength | 520nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 1W |
| Fast Axis Divergence | 45Deg |
| Slow Axis Divergence | 10Deg |
| Electrical | |
| Operating Current Iop | 1.4A |
| Threshold Current Ith | 0.2A |
| Operating Voltage Vop | 5.4V |
| Thermal | |
| Test Temperature | 0~60℃ |
| Storage Temperature | -40~85℃ |
Drawing:
