Description
Focuslight Laser Stack Module with 5Bars
Features:
Micro channel, 100w per bar
Focus Light laser diode stack 3bar 4bar 5bar optional
Unique gold coating technology with high reliability and stability
Every stack will be fully tested and had 8 hours burning test.
Quality warranty is 18months. No. of shots: >30millions.
Spec sheet
Item No.:WC808VS500
| Optical | |
| Center Wavelength | 808nm |
| Output Power Per Bar | 100W |
| Number of Bars | 5 |
| Pulse Width | ≤400ms |
| Duty Cycle | ≤40% |
| Electrical | |
| Operating Current Iop | ~100A |
| Threshold Current Ith | ~10A |
| Operating Voltage Vop | ~12V |
| Power Conversion Efficiency | ~50% |
| Thermal | |
| Operating Temperature | 20~30℃ |
| Storage Temperature | 0-55℃ |
Drawing
![{]]PTL2}`I@TXG5T)}IUR@4](/Content/uploads/202098745/20200710135017cb3c6a776ab348ad85bf00f00bb441a4.png)
